The Ajax Curtain Outdoor motion sensor is designed for outdoor protection where a narrow detection zone is required. Installed flush to a wall, it helps secure specific areas of a site, particularly where coverage needs to avoid vegetation or focus on certain access points.

With an adjustable range of up to 12 meters, the Ajax Curtain Outdoor can be configured to monitor windows and doors while excluding high-traffic zones such as walkways. Sensitivity levels can be set to low in areas where false alarms are more likely, medium for typical outdoor environments, and high in open areas where prompt detection is important.

The sensor uses dual motion detection technology, combining two PIR sensors with a Ka-band microwave sensor to reduce false alarms caused by thermal noise, animals, or moving plants. Detection range and pet immunity are adjusted using a slider on the device itself, while sensitivity is configured through the Ajax mobile or desktop apps to suit the specific requirements of the installation site.

The Ajax Curtain Outdoor is not compatible with the Hub 1.

EAN: 4823114026591 SKU: 1939055-81-WH1-1 Categories: , , Tag:

Delivery info

We deliver free of charge to our customers in SA. Delivery is generally within 2-5 working days, depending on your location.

Stock availability

If you can add an item to your shopping cart, we have it in stock on OUR shelves

Returns Policy

Not the right item? Amatron has a return policy of 14 days from the delivery date. Please note, returned products with damaged packaging cannot be swapped or refunded.

Warranty

The warranty for Ajax devices is valid for two years after the purchase date and does not apply to the supplied battery.

The Byrna HD launcher has a 1-year warranty. Using third-party projectiles or CO2 canisters with your Byrna HD will void your warranty.

Similar Products

Ajax MotionCam Outdoor
Ajax MotionCam Outdoor
-18%
Purchase & earn 864 points!Add to cart

Ajax MotionCam Outdoor

Original price was: R5,259.00.Current price is: R4,320.00. inc. VAT
Rated 0 out of 5
( 0 reviews )
Motion Dectector
Wireless Motion Dectector
-12%
Clear
Earn up to 599 points.Select options This product has multiple variants. The options may be chosen on the product page

Ajax MotionProtect Outdoor Sensor

Original price was: R3,399.00.Current price is: R2,995.00. inc. VAT
Rated 0 out of 5
( 0 reviews )
Dual Curtain Outdoor
Dual Curtain Back
-16%
Purchase & earn 704 points!Add to cart

Ajax DualCurtain Outdoor

Original price was: R4,199.00.Current price is: R3,520.00. inc. VAT
Rated 0 out of 5
( 0 reviews )

Description

Download User's Guide

Additional information

Color

White
Power supply

Battery
2 × CR123A
Pre-installed.

Type
type C

Calculated battery life
up to 3 years

Detector’s operating voltage range
4.1−6.2 V⎓

Detector’s nominal operating voltage
6 V⎓

Quiescent detector’s current consumption at nominal voltage
37 μA

Maximum detector’s current consumption at nominal voltage
600 mA

Full battery capacity
1,600 mAh

Low battery voltage
4.48 V⎓

Low battery recovery voltage
5.14 V⎓

End-of-life battery voltage
4.1 V⎓
Device is switched off.

End-of-life battery capacity
170 mAh

Manufacturer
Huiderui or Panasonic
Communication

Jeweller communication technology
Proprietary wireless communication technology to transmit commands, alarms, and events.

Key features:
● Two-way communication.
● Advanced anti-sabotage.
● Block encryption featuring a dynamic key.
● Instant notifications.
● Remote control and configuration in Ajax apps.

Frequency bands
866.0–866.5 MHz
868.0–868.6 MHz
868.7–869.2 MHz
905.0–926.5 MHz
915.85–926.5 MHz
921.0–922.0 MHz
Depends on the sales region.

Maximum effective radiated power (ERP)
up to 20 mW
Automatic power control to reduce power consumption and radio interference.

Radio signal modulation
GFSK

Radio communication range
up to 1,700 m
up to 5,500 ft
Between the detector and a hub (or a range extender) in an open space.

Encrypted communication
All stored and transmitted data are protected by block encryption featuring a dynamic key.

Frequency hopping
To prevent radio interference and jamming.

Wings communication technology
Proprietary wireless communication technology for uploading firmware updates.
Key features:
● Two-way communication.
● Advanced anti-sabotage.
● Block encryption featuring a dynamic key.
● Data packages reload in case of transmission errors.

Frequency bands
866.0–866.5 MHz
868.0–868.6 MHz
868.7–869.2 MHz
905.0–926.5 MHz
915.85–926.5 MHz
921.0–922.0 MHz
Depends on the sales region.

Radio communication range
up to 1,700 m
up to 5,500 ft
Between the detector and a hub (or a range extender) in an open space.

Encrypted communication
All stored and transmitted data are protected by block encryption featuring a dynamic key.

Frequency hopping
To prevent radio interference and jamming.
Detection

Sensitive elements
2 × PIR sensors
1 × K-band microwave sensor
K-band microwave sensor to prevent false alarms caused by thermal interference.
Operation frequency: 24 GHz.

Motion detection distance
up to 8–12 m
up to 26–39 ft
When installed at a height of 1–2.4 m. Adjusted with a slider at the detector enclosure.
When installed at a height of 3.3–7.9 ft. Adjusted with a slider at the detector enclosure.

Motion detection angles
horizontal: 8°
vertical: 85°/15°
Depends on the installation height. The angle is 85° at 2.4 m (7.9 ft) and 15° at 1 m (3.3 ft).

Motion detection speed
0.3 to 2.0 m/s
1 to 6.6 ft/s
The direction of the detector lens should be perpendicular to an alleged intrusion path into the facility.

Sensitivity
3 levels
Adjusted by a PRO or a user with admin rights in the Ajax apps.

Pet immunity
height: up to 100 cm (3.3 ft)
weight: irrelevant
The detector should be installed at a height of 1 meter, and the slider on its enclosure should be set to the Pet position.
The detector should be installed at a height of 3.3 feet, and the slider on its enclosure should be set to the Pet position.

False alarm prevention
Dual motion detection technology
SmartDetect
Software algorithm.

Temperature compensation
Effective motion detection at temperatures from −25 °C to +60 °C.
(−13 °F to +140 °F)
Recommendations

It is recommended to install the detector at a height of:
● 2.4 m (7.9 ft);
● 1 m (3.3 ft) when the Pet immune mode is enabled.

The device is designed for indoor and outdoor use.

Install the hood to protect the detector’s anti-masking system from rain and snow.
Sabotage protection

Tamper alarm
Notifications on attempts to detach the detector from the surface or remove it from the mounting panel.

Protection against spoofing
device authentication

Anti-masking system
detects attempts to block the detector view

Accelerometer
alarm when the detector is moved
Must be activated when the detector is installed on third-party brackets.

Holding screw
To secure the detector on SmartBracket or hood.

Communication loss detection
after 36 s
Detection time depends on Jeweller or Jeweller/Fibra settings.
Enclosure

Dimensions with hood
155 × 77 × 85 mm
6.1″ × 3.03″ × 3.35″

Dimensions with hood and angle mount
155 × 84 × 98 mm
6.1″ × 3.31″ × 3.86″

Dimensions without hood
141 × 60 × 72 mm
5.55″ × 2.36″ × 2.83″

Dimensions without hood and with angle mount
141 × 76 × 84 mm
5.55″ × 2.99″ × 3.31″

Weight with hood
TBC

Weight without hood
223 g
7.87 oz

Weight of angle mount
34 g
1.2 oz

Operating temperature range
from −25 °C to +60 °C
from –13 °F to +140 °F

Operating humidity
up to 95%

Protection class
IP55
Complete set

Curtain Outdoor Jeweller
SmartBracket mounting panel
2 × CR123A battery (pre-installed)
Angle mount
Hood
Installation kit
Quick start guide
Warranty

Replacement and repair within 24 months of the date of sale. Batteries are not covered under warranty.
